SSQ 21D HF
Technical Specifications
What makes our Worky Quads with “High Flow” hydraulic system so special? The answer is simple: exceptional power and fluidity. All the high flow power you need combined with a diesel engine. Thanks to the new system that allows for greater hydraulic flow, WorkyQuad WX21 HF can deliver extraordinary power and transform it into traction thanks to the large tracks, allowing it to overcome any obstacle.
| General | |
|---|---|
| Manufacturer | Worky Quads |
| Category | Loader |
| Price | Request a Quote |
| Model | SSQ 21D HF |
| Year | 2025 |
| Condition | New |
| Type of Engine | KUBOTA Z602-E4B |
| Capacity (kW/Hp) | 21 |
| Start up | Electric |
| Displacement cm3/ number of cylinders | 599/2 |
| Revolutions per minute (rpm) | 3200 |
| Adjusted amount of revolutions (rpm) | 3600 |
| Cooling | Liquid |
| Fuel/ fuel tank capacity(l) | Diesel/ 20 |
| Drive system | Hydrostatic 4WD wheels motor |
| Speed (MPH) | 0-4 (proportional) |
| Lifting capacity (Lbs) | 772 |
| Traction force (Lbs) | 900 |
| Hydraulic drive system (Gal/bar) | 7/7 |
| Hydraulic working system (Gal/bar) | 7/7 |
| Hydraulic tank capacity (G) | 4 |
| Standard tyres | 23×8.50-12 Skid |
| Electrical system (V) | 12 |
| Battery capacity(Ah) | 45 |
| Braking system | Hydrostatic with 4 hydraulic wheels motor |
| Steering | Skid Steering |
| Hydraulic capacity (Lbs) | 1322 |
| Breakout force (Lbs) | 661 |
| Dimensions (L in x W in x H in) | 60x41x50 |
| Weight (Lbs) | 1512 |
| (The a.m. informations may change) |
